Material: SS304, SS316
A CF (ConFlat) Nonrotatable Reducing Adapter is a vacuum component used in high vacuum systems. It is used to connect two vacuum components with different-sized flanges while preventing rotational movement between the two components.
The reducing adapter has a smaller flange size on one end and a larger flange size on the other end, allowing it to connect two vacuum components with different flange sizes. The nonrotatable feature of the adapter means that it has a locking mechanism that prevents rotational movement between the two connected components.
CF Nonrotatable Reducing Adapters are made of a corrosion-resistant material, such as stainless steel, and are designed to withstand high vacuum pressure, high temperatures, and corrosive gases. They are designed to be used with CF Flanges, which are standardized flanges commonly used in high vacuum systems.
Spec | A | B | C | D |
CF35RA16 | 70 | 34 | 76 | 19.05 |
CF35RA25 | 70 | 54 | 76 | 25.4 |
CF63RA16 | 114 | 34 | 76 | 19.05 |
CF63RA25 | 114 | 54 | 76 | 25.4 |
CF63RA35 | 114 | 70 | 76 | 38.1 |
CF100RA35 | 152 | 70 | 76 | 38.1 |
CF100RA63 | 152 | 114 | 76 | 63.5 |
CF150RA35 | 202 | 70 | 76 | 38.1 |
CF150RA63 | 202 | 114 | 76 | 63.5 |
CF150RA100 | 202 | 152 | 76 | 101.6 |
