Double Stage Rotary Vane Vacuum Pump
275 m3/h double stage rotary vane vacuum pump is a powerful and efficient pump that is designed for industrial applications requiring high vacuum levels. This pump features two stages of compression, which allows it to achieve a high level of vacuum with minimal noise and vibration.
DRV275 Series Double Stage Rotary Vane Vacuum Pump
High Capacity · Deep Vacuum · Industrial Reliability
The DRV275 Double Stage Rotary Vane Vacuum Pump is a high-capacity vacuum solution designed for demanding industrial and laboratory applications. With a large pumping speed of 275 m³/h, it enables rapid evacuation and stable high-vacuum performance.
High Pumping Speed for Fast Evacuation
The 275 m³/h pumping speed significantly reduces evacuation time, making the DRV275 ideal for systems requiring fast response and high throughput.
Double Stage Design for Deeper Vacuum
The two-stage rotary vane construction delivers deeper ultimate vacuum and higher efficiency compared to single-stage pumps.
Efficient and Stable Performance
Proven rotary vane technology ensures consistent vacuum performance and reliable continuous operation.
Easy Maintenance
Accessible components simplify routine maintenance, helping reduce downtime and operating costs.
Robust and Durable Construction
Built with high-quality materials and precision engineering, the DRV275 is designed for long service life under demanding industrial conditions.
| Model | DRV275 | ||
| Pumping speed | 50Hz | m3/h | 255 |
| 60Hz | 306 | ||
| Ultimate Vacuum | GB Closed | Pa | 0.5 |
| GB Open | 2 | ||
| Motor Power | 380V(3ph) | kW | 7.5 |
| 220v(1ph) | kW | / | |
| Inlet | VG80 | ||
| Outlet | VG50 | ||
| Vacuum Pump Oil | BSO68 | ||
| Oil Capacity | L | 23~28 | |
| Weight | kgs | 236 | |
Vacuum Coating, Vacuum Impregnation, Industrial Vacuum Systems, Chemical and Pharmaceutical Industries, Power Plants, Semiconductor Manufacturing, Food Processing and Packaging, Environmental Applications, Vacuum Conveying Systems, Vacuum Degassing, Central Vacuum Systems, Freeze Drying, Vacuum Furnaces, Leak Detection, Research and Development, Solar Panel Manufacturing, Evaporation and Distillation, Vacuum Lifting and Handling.
